Dimensions
- Outer Diameter: 99 mm (3.9 in)
- Inner Diameter: 41 mm (1.6 in)
- Height: 231 mm (9.1 in)
- Length: 235.7 mm (9 9/32 in)【^7^】
Technical Specifications
- Media Type: E Media (Cellulose)
- Nominal Filter Rating: 25 µm
- Connection Type: Seal
- Seal Material: Buna
- Beta Ratio: 200
- Efficiency: 99.5%
- Max Operating Pressure: 10.3 bar (150 psi)
- Operating Temperature Range: -29 ºC (-20 ºF) to 107 ºC (225 ºF)
- Weight: 0.64 kg (1.4 lb)【^1^】【^2^】
Compatible Equipment
- Compatible Equipment: This filter element is designed for use with Schroeder filter housings.
Industry Applications
- Industry Applications: Primarily used for filtration in hydraulic and lubrication systems, widely applicable in:
- Automotive
- Agriculture
- Industrial Equipment
- Marine
- Mining
- Oil and Gas【^2^】【^3^】
Related Similar Models
- Similar Models:
- KTZ10
- KTZ25
- KF3
- KFT【^5^】【^6^】
You know you have received a quality DeMalong Filter hydraulic filter when you our logo on the filter box with our brand name and part number.
Our filters are built with the highest quality and reliability in mind so you know your equipment is safe and can keep running smoothly.
DeMalong Filter hydraulic filters can be used in a variety of industries including but not limited to: power generation, defense, oil/gas, marine and other motor sports, shipping and transportation, railroad, mining, pulp and paper, steel making and manufacturing, entertainment and various other industries.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc.) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of DeMalong Filter Inc. filter with the OEM filter.
Images may be general representations of products and may vary from image. All items are sold by 1 unit unless a pack size is listed in the title description.
