The following is the basic information of CHP283F10XN and CHP622F10XN hydraulic filter elements:

CHP283F10XN hydraulic filter element

Filter accuracy: 10 microns.

Filter element material: glass fiber.

Seal material: nitrile rubber (NBR).

Working pressure: up to 150 psi.

Working temperature: up to 250°F.

Dimensions:

Total height: about 9.25 inches.

Outer diameter: 1.75 inches.

Inner diameter: none.

Flow direction: outside to inside.

Application areas: widely used in hydraulic systems such as steel mills, wind power plants, coal mining equipment, etc.

Features: strong corrosion resistance, reasonable structural design, easy to replace and clean.

CHP622F10XN hydraulic filter element

Filter accuracy: 10 microns.

Filter element material: micro glass fiber.

Seal material: fluororubber (Viton).

Working pressure: up to 305 psi.

Working temperature: -13°F to 250°F.

Dimensions:

Overall height: about 9.25 inches.

Outer diameter: 3.16 inches.

Inner diameter: 1.60 inches.

Flow direction: outside to inside.

Application: Suitable for return oil filtration of hydraulic system, can effectively filter metal particles, dust and moisture.

Features: high filtration efficiency, large dirt holding capacity, long service life.
